參數名稱 | 適合壓機內寬 (mm) |
布料有效寬度 (mm) |
推料架行程 |
適合壓制最 大瓷磚規格 |
實現喂料次數 (c/min) |
壓縮空氣壓力 |
總功率 (kW) |
外形尺寸 (mm) |
總 重 (kg) |
---|---|---|---|---|---|---|---|---|---|
KL1600/600 |
≥1600 |
1450 |
1140 | 600 | ≤15 | ≥0.5 | 7 | 2500×2110×2100 | 1400 |
KL1700/600 |
≥1700 |
1550 | 1140 | 600 | ≤15 | ≥0.5 | 7 | 2500×2110×2100 | 1400 |
KL1750/600 | ≥1750 | 1600 | 1140 | 600 | ≤15 | ≥0.5 | 7 | 2500×2110×2100 | 1400 |
KLG1750/1000 | ≥1750 | 1520 | 1700 | 1000 | ≤14 | ≥0.5 | 6 | 2800×2620×2100 | 1350 |
KLG1850/1000 | ≥1850 | 1620 | 1700 | 1000 | ≤14 | ≥0.5 | 6 | 2800×2720×2100 | 1350 |
KLG1900/1000 | ≥1900 | 1670 | 1700 | 1000 | ≤14 | ≥0.5 | 6 | 2800×2770×2100 | 1350 |
KLG2050/1000 | ≥2050 | 1820 | 1700 | 1000 | ≤14 | ≥0.5 | 8 | 2800×3120×2100 | 1450 |
KLG2200/1200 | ≥2200 | 1970 | 1700 | 1000 | ≤14 | ≥0.5 | 8 | 2800×3120×2100 | 1550 |
KLG2250/1000 | ≥2250 | 2020 | 1700 | 1000 | ≤14 | ≥0.5 | 8 | 2800×3120×2100 | 1550 |
KLG2400/1000 | ≥2400 | 2140 | 1800 | 1200 | ≤10 | ≥0.5 | 8 | 2800×3320×2100 | 1650 |
KLG2450/1200 | ≥2450 | 2190 | 1800 | 1200 | ≤10 | ≥0.5 | 8 | 2800×3300×2100 | 1650 |
KLG2500/1200 | ≥2500 | 2240 | 2300 | 1200 | ≤10 | ≥0.5 | 8 | 3140×3370×2100 | 1800 |
KLG2850/1200 | ≥2850 | 2610 | 1800 | 1200 | ≤9 | ≥0.5 | 8 | 3000×3720×2200 | 2000 |
KLG3350/1200 | ≥3350 | 3000 | 2200 | 1200 | 8 | ≥0.6 | 6.5 | 3600×4000×2000 | 2150 |
